B Type RCBO B16 0.03A RCBO 16 Amp 30mA B16 Type B RCD 16A Circuit Breaker

Product Categories
Shanghai Hengyi Mechanical&Electrical Engineering Co., Ltd.
Contact Now

B Type RCBO B16 0.03A RCBO 16 Amp 30mA B16 Type B RCD 16A Circuit Breaker

Contact Now

B Type RCBO B16 0.03A RCBO 16 Amp 30mA B16 Type B RCD 16A Circuit Breaker

Short Description:

B Type RCBO 40A 63A 30mA 3 Phase 400V B32 EKL5-63B

We strive for excellence, services the customers, hopes to be the top cooperation team and dominator business for personnel, suppliers and prospects, realizes benefit share and continual promotion for Competitive Price for China Professional Manufacturer Highly Top Quality Mini Circuit Breaker and Residual Current Circuit Breaker, Top quality will be the key factor with the company to stand out from other competitors. Seeing is Believing, want more data? Just trial on its merchandise!

Competitive Price for China Circuit Breaker, Breaker, Taking the core concept of to be the Responsible”. We are going to redound up on society for high quality merchandise and good service. We are going to initiative to participate in international competition to be a first- class manufacturer of this product in the world.


  • Rated Current: 16A
  • Poles: 4Pole (3P+N) +B16 MCB
  • Rated voltage: 4Pole: 400V/415V
  • Rated frequency 50/60Hz
  • Rated residual operation current: 30mA ,100mA ,300mA
  • Short-circuit current: Inc= I c 10000A
  • Standard: IEC 61008-1 , IEC 62423
    • Send email to usSend email to us

    Product Detail

    Product Tags

    We strive for excellence, services the customers, hopes to be the top cooperation team and dominator business for personnel, suppliers and prospects, realizes benefit share and continual promotion for Competitive Price for China Professional Manufacturer Highly Top Quality Mini Circuit Breaker and Residual Current Circuit Breaker, Top quality will be the key factor with the company to stand out from other competitors. Seeing is Believing, want more data? Just trial on its merchandise!

    Competitive Price for China Circuit Breaker, Breaker, Taking the core concept of to be the Responsible”. We are going to redound up on society for high quality merchandise and good service. We are going to initiative to participate in international competition to be a first- class manufacturer of this product in the world.

    Item Type B RCBO
    Product Model HENGYI-80BO
    Rated Current 16A , 20A , 25A , 32A , 40A , 50A , 63A
    Poles 2Pole (1P+N) 4Pole (3P+N)
    Rated voltage Ue 2Pole 240V~ 4Pole 415V~
    Reference Standard IEC61009-1 , IEC62423
    Tripping Characteristics B / C
    Insulation Voltage 500V
    Rated frequency 50/60Hz
    Rated residual operation current(I n) 30mA , 100mA , 300mA
    Short-circuit current Inc= I c 6000A
    Energy limiting class 3
    Rated impulse withstand voltage(1.5/50) Uimp 4000V
    Dielectric test voltage at ind.Freq. for 1min 2kV
    Electrical life 4000 Cycles
    Mechanical life 10000 Cycles
    Protection Degree IP20
    Ambient temperature -5℃ upto +40℃
    Storage temperature -25℃ upto +70℃
    Terminal connection type Cable/Pin type busbar
    U-type busbar
    Terminal size top/bottom for cable 25mm 18-3AWG
    Terminal size top/bottom for busbar 25mm 18-3AWG
    Tightening torque 2.5Nm 22In-Ibs
    Mounting On DIN rail EN60715(35mm)
    by means of fast clip device
    Connection From top
    Combination
    with
    accessories    		 Auxiliary contact EKM1-OF
    Alarm contact EKM1-FB
    Shunt release EKM1-MX

  • Previous: 40A 63A Type A RCBO 4Pole 30mA 50Hz B32 MCB Circuit Breaker
  • Ne







    • Quality B Type RCBO B16 0.03A RCBO 16 Amp 30mA B16 Type B RCD 16A Circuit Breaker for sale
